Feature
1 PLC controlled system, touch screen operation, at the same time you can operate with manual operation button.
2.Easy to operate, require1-2 individual workers operating.
3. Grip conveyor band system durable to all kinds of chemical and detergent.
4.Main parts manufactured with 304 stainless steel.
5 .save the energy, water and labor cost .
6. Waste water disposal pool collects waste water.
7.washing width can be adjustable,
8.low cost .
|
型號 |
Model |
XDT-1600 |
XDT-2000 |
XDT-2500 |
XDT-3200 |
XDT-4200 |
|
刷子數(shù)量 |
Brush quantity |
5 |
5 |
6 |
6 |
10 |
|
最大洗滌寬度（m） |
Max.wash width(m) |
1.6 |
2 |
2.5 |
3.2 |
4.2 |
|
工作效率（m2/h） |
washing speed
(m2/h)
|
40 |
50 |
55 |
90 |
120 |
|
平均洗滌時間（min） |
average washing time (min) |
5 |
5 |
5 |
5 |
5 |
|
耗水量（L/m3） |
washer consumption (L/m3) |
30 |
30 |
30 |
30 |
30 |
|
耗電量（kw/m2） |
electric consumption (kw/m2) |
0.075 |
0.075 |
0.075 |
0.075 |
0.075 |
|
額定功率（kw） |
rated power(kw) |
3 |
3.5 |
3.5 |
3.5 |
7.5 |
|
刷子速度（r/min） |
brush speed (r/min) |
0-500 |
0-500 |
0-500 |
0-500 |
0-500 |
|
蠕動泵數(shù)量 |
peristaltic pump Qty |
1 |
1 |
1 |
1 |
1 |
|
水泵數(shù) |
water pump Qty |
1 |
1 |
1 |
1 |
1 |
|
儲水盒 |
Water storage box Qty |
1 |
1 |
1 |
1 |
1 |
|
觸摸面板 |
touch panel |
1 |
1 |
1 |
1 |
1 |
|
進(jìn)水管(inch) |
water inlet (inch) |
1/2 |
1/2 |
1/2 |
1/2 |
1/2 |
|
自動卷 |
automatic roll |
1 |
1 |
1 |
1 |
1 |
|
速度m/min |
speed (m/min) |
0.6 |
0.6 |
0.6 |
0.6 |
0.6 |
|
電壓（v） |
voltage(V) |
380 |
380 |
380 |
380 |
380 |
|
尺寸(mm) |
dimension (mm) |
2.2*2*1.8 |
3*2*1.8 |
3.5*2*1.8 |
4.6*2*1.8 |
5.4*2*1.8 |
|
重量（kg) |
weight(kg) |
520 |
620 |
720 |
1000 |
1200 |
|
 |
 |
 |
 |
|
|
|
